16001 Koyo ญี่ปุ่นแท้100% 12x28x7 mm. ลูกปืน อะไหล่รถมอเตอร์ไซค์ Motorcycle JTEKT

Deep Groove 16001 Ball Bearings 12x28x7 mm. ลูกปืน อะไหล่รถมอเตอร์ไซค์ Motorcycle Koyo Japan
Koyo Bearing 16001 (ID:12mm x OD:28mm x W:7mm) CR Water Pumps Each

16001
Contact us
Global Network
Back to product search
Print layout
Deep groove ball bearings - Single-row - Open type

Specifications
(Boundary dimensions ...etc)
d 12 mm
D 28 mm
B 7 mm
r(min.) 0.3 mm
Basic load ratings : Cr 6.40 kN
Basic load ratings : C0r 2.40 kN
Fatigue load limit : Cu 0.120 kN
factor : f0 13.2
Limiting speeds(Grease lub.) 27000 min-1
Limiting speeds(Oil lub.) 32000 min-1
Mounting dimensions
da(min.) 14 mm
Da(max.) 26 mm
ra(max.) 0.3 mm
Refer.
(Refer.)Mass 0.024 kg
