4210 Koyo - Deep Groove Ball Bearing Double Row 50x90x23 ลูกปืนเม็ดกลม สองแถว

4210 Koyo - Deep Groove Ball Bearing Double Row 50x90x23 ลูกปืนเม็ดกลม สองแถว
Deep groove ball bearings 4210
Bearing number : 4210

Size (mm) : 50x90x23

Brand : KOYO

Bore Diameter (mm) : 50

Outer Diameter (mm) : 90

Width (mm) : 23

Bearing dimensions and specification in KOYO catalogue:

d - 50 mm

D - 90 mm

B - 23 mm

C - 23 mm

r min. - 1.1 mm

da min. - 56.5 mm

Da max. - 83.5 mm

ra max. - 1 mm

Weight - 0.651 Kg

Basic dynamic load rating (C) - 31.4 kN

Basic static load rating (C0) - 44.6 kN

(Grease) Lubrication Speed - 4200 r/min

(Oil) Lubrication Speed - 5600 r/min

Calculation factor (f0) - 16.1

Tags : KOYO , 50x90x23
