Koyo 5211 (55x100x33.3) ลูกปืนเม็ดกลมสัมผัสเชิงมุม 2 แถว (DOUBLE ROW ANGULAR CONTACT BALL BEARING )

Koyo 5211 (55x100x33.3) ลูกปืนเม็ดกลมสัมผัสเชิงมุม 2 แถว ( DOUBLE ROW ANGULAR CONTACT BALL BEARING )

5211
Product information
Back to product search
Print layout
Angular contact ball bearings - Double-row - Open

Specifications
(Boundary dimensions ...etc)
d 55 mm
D 100 mm
B 33.3 mm
r(min.) 1.5 mm
Basic load ratings : Cr 82.3 kN
Basic load ratings : C0r 55.2 kN
Fatigue load limit : Cu 2.85 kN
Limiting speeds(Grease lub.) 3800 min-1
Limiting speeds(Oil lub.) 5100 min-1
Load center spread : a 50.2 mm
Mounting dimensions
da(min.) 64 mm
da(max.) - mm
Da(max.) 91.5 mm
ra(max.) 1.5 mm
