SKF แบริ่งลูกกลิ้งทรงกลม 21319 EK, 95X200X45mm 21319 EK แบริ่งลูกกลิ้งทรงกลม, รุ่นเก่า 21319 EK รู K

แบริ่งลูกกลิ้งทรงกลม 21319 EK, 95X200X45mm
21319 EK แบริ่งลูกกลิ้งทรงกลม, รุ่นเก่า 21319 EK, ขนาด: 95X200X45mm (IDxODxB)

21319 EK
Spherical roller bearing with tapered bore and relubrication features
Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.
Accommodate misalignment
High load carrying capacity
Relubrication features
Low friction and long service life
Increased wear resistance
View product table
Calculate rating life, frequencies etc.
Download PDF
OVERVIEW
TECHNICAL SPECIFICATION
CAD
COMPATIBLE PRODUCTS
MOUNTING
MORE INFORMATION
Display in:
Dimensions
Bore diameter95 mm
Outside diameter200 mm
Width45 mm
Performance
Basic dynamic load rating433 kN
Basic static load rating490 kN
Reference speed3 400 r/min
Limiting speed4 500 r/min
SKF performance classSKF Explorer
