SKF 21312 E SphericalRollerBearings 21312 E, ขนาด: 60X130X31 มม. (IDxODxB) ตลับลูกปืนลูกกลิ้งทรงกลม

ตลับลูกปืนลูกกลิ้งทรงกลม
21312 E
Spherical roller bearing with relubrication features
Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.
Accommodate misalignment
High load carrying capacity
Relubrication features
Low friction and long service life
Increased wear resistance
คำนวณอายุการใช้งาน ความถี่ ฯลฯ
Download PDF
ภาพรวม
ข้อมูลจำเพาะทางเทคนิค
CAD
MOUNTING
แสดงใน:
Dimensions
Bore diameter60 mm
Outside diameter130 mm
Width31 mm
Performance
Basic dynamic load rating217 kN
Basic static load rating240 kN
Reference speed4 800 r/min
Limiting speed6 300 r/min
SKF performance classSKF Explorer
